Pipe clamp
Item no. 5102111 | EAN 4012195399971
- Product description
-
Product description• DIN 48818, Form D
• With Ø 11 mm mounting hole
• 2 hexagonal bolts M8 x 20 (4 inch = M10)
• 2 hex-head nuts M8 (4 inch = M10)
- Technical data
-
Technical data
Bimetal connector no Clamping range, min. 33,7 mm Connection hole 11 mm Dimension 1" Dimension d min. 33,7 mm explosion-proof no for pipe 1 Integrated round conductor guide no Material Steel Surface Hot-dip galvanised - All types
-
All types
- Downloads
-
Data sheet 303 DIN-1 / 5102111 , 0.15MB , pdfEU declaration of conformity 303 DIN-1 / 5102111 , 0.06MB , pdfREACH Declaration of conformity 303 DIN-1 / 5102111 , 0.27MB , pdfRoHS Declaration of conformity 303 DIN-1 / 5102111 , 0.12MB , pdf
