Note: This article is discontinued.
You can find the current article here: 6038112 / T piece 60 FS
- Product description
-
Product description
Tee branch piece with quick connector system. For all cable tray types of 60 mm side height.
- Technical data
-
Technical data
Bend (angle) 90° Change of direction Horizontal Connector version Integrated connector Dimension 60x600 Fire protection Use of fire protection ceilings Maintain electrical functions no Material Steel NATO hole pattern no Plate thickness 1,25 mm Rail thickness 1,25 mm Rustproof steel, pickled no Surface Strip galvanized Type T piece horizontal Type of connector, cable support system Screwed Wide-span version no Dimensions
Dimension B 600 mm Height 60 mm Width 24 in Width 600 mm - All types
-
All types
- Downloads
-
Data sheet RTM 660 FS / 6041332 , 0.23MB , pdfCatalogue Kabeltragsysteme , 45.23MB , pdfDeclaration of conformity RTM 660 FS / 6041332 , 0.10MB , pdfUK Declaration of Conformity RTM 660 FS / 6041332 , 0.14MB , pdfREACH Declaration of conformity RTM 660 FS / 6041332 , 0.12MB , pdfRoHS Declaration of conformity RTM 660 FS / 6041332 , 0.12MB , pdfMounting instructions General information on the mounting , 2.61MB , pdf
